YAMAHA IS THE EASY CHOICE.

Our only questions for you is refill or recharge.

CODE:
JC0
TYPE:
SINGLE CYLINDER 60° INLCINE OHV
TOTAL DISPLACEMENT:
357
BORE X STROKE:
85 x 63
COMPRESSION RATIO:
8:1
MAXIMUM OUTPUT (kW/rpm):
6.7/3.400/8.9 hp
MAXIMUM TORQUE (Nm/rpm):
25.5/2500
COOLING SYSTEM:
FORCED COOLING
FUEL SYSTEM:
Electronic Fuel Injection
STARTING SYSTEM:
STARTER/ GENERATOR
IGNITION SYSTEM:
TRANSISTOR
LUBRICATION SYSTEM:
SPLASH
TYPE OF CARBURETOR:
SPECIAL DESIGN FOR JC0 (AISAN)
TYPE OF AIR CLEANER:
OIL SPREAD OVER PLEATED PAPER + URETHANE FOAM PRE FILTER
TYPE OF IGNITION PLUG:
BPR2ES/BPR4ES
OIL CAPACITY:
1
FUEL CONSUMPTION g/kWh:
294
BALANCER TYPE:
Single shaft
DRY WEIGHT:
22
DIMENSIONS (LxWxH):
430x365x350
CODE:
JR6
TYPE:
SINGLE CYLINDER 60° INLCINE OHV
TOTAL DISPLACEMENT:
357
BORE X STROKE:
85 x 63
COMPRESSION RATIO:
8:1
MAXIMUM OUTPUT (kW/rpm):
6.7/3.400/8.9 hp
MAXIMUM TORQUE (Nm/rpm):
25.5/2500
COOLING SYSTEM:
FORCED COOLING
FUEL SYSTEM:
Carburetor
STARTING SYSTEM:
STARTER/ GENERATOR
IGNITION SYSTEM:
TRANSISTOR
LUBRICATION SYSTEM:
SPLASH
TYPE OF CARBURETOR:
BV26-18
TYPE OF AIR CLEANER:
OIL SPREAD OVER PLEATED PAPER + URETHANE FOAM PRE FILTER
TYPE OF IGNITION PLUG:
BVR2ES/BPR4ES
OIL CAPACITY:
1
DRY WEIGHT:
22
TYPE:
48V AC
MOTOR TYPE:
AC
MOTOR RATED VOLTAGE (v):
48
MOTOR RATED OUTPUT (kW):
5.0 kW (6.7 hp) for 60 minutes
MOTOR HEAT RESISTANCE:
CLASS H
MOTOR CONTROLLER:
NEOS 350 amp AC by TOYOTA Industrial Corporation.
MOTOR CHARGER:
YAMAHA-built automatic microprocessor-based high frequency switching regulated charger.
TYPE:
48V DC
MOTOR TYPE:
DC SHUNT WOUND
MOTOR RATED VOLTAGE (v):
48
MOTOR RATED OUTPUT (kW):
2.6
MOTOR HEAT RESISTANCE:
CLASS H
MOTOR CONTROLLER:
FET CHOPPER
MOTOR CHARGER:
YAMAHA-built automatic microprocessor-based high frequency switching regulated charger.
